Vacuum Plates for Special-Shaped Jars
Custom Vacuum Solutions for Irregular Jar Geometries
Sprint Drives offers a specialized range of Vacuum Plates designed to securely grip and handle jars with non-standard shapes during palletizing, depalletizing, or transfer operations. These plates are engineered to accommodate unique geometries—such as wide bodies, tapered necks, or asymmetrical profiles—ensuring reliable vacuum hold without damaging delicate glass surfaces. Ideal for use in high-speed production environments, they are tailored to fit each jar profile and production layout.
Technical Specifications
Material Composition: Multi-layer design including a high-density foam base, polymer-coated surface, and bonded structural backing
Surface Hardness: Available in soft, medium, or firm foam densities depending on jar weight and handling needs
Dimensions & Shape: Fully customizable to match jar footprint, neck diameter, and packing pattern
Sealing Options: Gasketed perimeters, embedded grooves, or bonded rubber edges to maintain vacuum seal
Food-Grade Options: Natural rubber or CE-grade rubber available for food contact zones
Mounting Compatibility: Drilled and fitted for universal or custom vacuum heads
Support Options: Plywood, PVC, or anodized aluminum plates for added hygiene and rigidity
Safety Warning
Ensure vacuum plate surface aligns precisely with jar contours. Do not use with cracked, chipped, or irregularly loaded jars. Regular cleaning and inspection are required, especially when handling glassware in food or beverage facilities.
Markets
Beverage Bottling Lines
Decorative Jar Printing Facilities
Glass Manufacturing Plants
High-Speed Palletizing & Depalletizing Systems
Features / Benefits
Tailored to each jar’s unique shape and handling conditions
Foam conforming surface absorbs impact and prevents slippage
Reduces breakage and vacuum loss in irregular pick-and-place operations
Hygienic build options for food-grade handling
Easily replaceable wear layers to extend service life
Compatible with robotic or manual vacuum heads
Applications
Handling of oval, tapered, or wide-mouthed jars
Secure transfer of jars in decorating or labeling systems
Precision placement in bottling and packaging operations
Custom pallet layouts with mixed or specialty jars
For more information or to place an order, please fill the quote form
